Batteriesystem Icon Kapazitaet
Power
22 kW
Batteriesystem Icon Energiedichte
Volt
500 V
Batteriesystem Icon Gewicht
Weight
34 kg

Applications

Passenger car
Individuelle Batteriesysteme Kleine Nutzfahrzeuge
Light commercial vehicles

Gewinner in der Kategorie Produkt Design

Designwerk ist Gewinner des Red Dot Design Awards in der Kategorie Produkt Design

Technical data

Dimensions LxWxH 500 × 240 × 440 (without trolley)
Weight 34 kg (without cable)
AC input data 22 kW, 3 x 32 A, 400 V +- 10 %, 45-65 Hz
AC plug type CEE 32, CEE 16, 3P + N + PE
DC output data 21 kW, 60 A, 250-500 V
DC connector type CCS Type 2, CCS Type 1, CHAdeMO, GB/T
Efficiency >96% from 30% load
Power factor >0.99 from 50% load
Conformity and safety CE, 2014/35/EG, IEC 61851, IEC61000-6-2,-3
Charging standard DIN70121, ISO15118, CHAdeMO-Ver.1.2/2.0, GB/T-27930-2015

You want to know it exactly?
Get direct access to detailed datasheets and updates on products and new developments.

Accessories

Mobiles Dc Schnellladegeraet Elektrofahrzeuge Zubehoer Mdc 22 500 Trolley Mit Kabelhalterung
Trolley with cable holder

The trolley ensures neat storage of cables and easy movement of the Mobile Charger.

Mobiles Dc Schnellladegeraet Elektrofahrzeuge Zubehoer Mdc Flight Case
Flight Case

With the Flight Case, your Mobile Charger is protected all around during transport. The cables can also be neatly stowed away.

Mobiles Dc Schnellladegeraet Elektrofahrzeuge Zubehoer Mdc 44 920 Wandhalterung
Wall mount

With the help of the wall mount incl. cable storage, the charger can be permanently mounted on the wall.

Mobiles Dc Schnellladegeraet Elektrofahrzeuge Zubehoer Mdc 22 500 Bodenhalterung
Floor holder

With the floor mount, your Charger finds its fixed place on the floor in your workshop or service vehicle.
